XBTN401K

Main

product line Magelis XBTN
Product or component type Small panel with keypad
screen resolution 122 x 32 pixels
software type Configuration software
software demonstration Vijeo Designer Lite
OS Magelis

Complementary

screen type Extra bright matrix backlit LCD
screen color Red
Green
Orange
character font ASCII
Katakana
Chinese (simplified Chinese)
Greek
Cyrillic
[Us] rated supply voltage 24V DC
feed External source
supply voltage limits 18…30V
residual fluctuation 1200mV
Maximum power consumption in W 5W
number of key 8
number of fixed keys 4
customizable number of keys 4
On-device signaling 6 LEDs
number of pages 256 alarm pages
200 application pages
memory type Flash
memory capacity 512 kB
integrated connection type Power supply: removable screw terminal block
Printer port: female mini DIN
Serial connection: female SUB-D 25, asynchronous transfer mode (RS232C/RS485) multi-plug topology
real time clock Access to PLC real time clock
product assembly Flush mounting
Fixing Mode With 2 spring clips
screen material Polyester
front material PPT
keypad material Polyester
Marking CE
Width 132mm
Height 74mm
Depth 43mm
cut sizes 119.4 (+/- 0.5) x 63 (+/- 0.4)mm
Product weight 0.38kg

Environment

message display capacity 4 lines of maximum 20 characters
1 line of at least 5 characters
downloadable protocols Uni-TE
Modbus
Third-party protocols
standards IEC 60068-2-6
IEC 61131-2
CSA C22.2 No 14
IEC 60068-2-27
UL 508
Product certificates UL 1604
ATEX zone 2/22
CSA Class 1 Division 2
UL Class 1 Division 2
Rated operating ambient temperature 0…55 °C
Storage ambient conditions -20…60 °C
Relative humidity 0…85 % non-condensing
IP degree of protection IP20 conforming to IEC 60529 (back panel)
IP65 conforming to IEC 60529 (front panel)
NEMA protection rating NEMA 4X front panel (outdoor use)
impact strength 11 ms for 15 gn
vibration resistance +/- 3.5mm[Area](f =[Area]2…8.45 Hz)
1 gn[Area](f =[Area]8.45…150 Hz)

Packing Units

Unit Type of Package 1 PCE
Number of Units in Package 1 One
Package 1 Height 4.5 cm
Package 1 Width 16.2cm
Package 1 Length 23.5cm
Package 1 440.0 g
Unit Type of Package 2 S03
Number of Units in Package 2 11th
Package 2 Height 30.0 cm
Package 2 Width 30.0 cm
Package 2 Length 40.0 cm
Package 2 Weights 5,495 kg
