HMIGTO5310

Main

Range of product Harmony GTO
Product or component type Advanced touchscreen panel
Display colour 65536 colours
Display size 10.4 inch
Supply External source
Operating system Harmony
Battery type Lithium internal RAM 100 days 5 day(s) 10 year(s)

Complementary

Terminal type Touchscreen display
Display type Backlit colour TFT LCD
Display resolution 640 x 480 pixels VGA
Touch sensitive zone 1024 x 1024
Touch panel Resistive film, 1000000 cycles
Backlight lifespan 50000 hours white 77 °F (25 °C)
Brightness 16 levels by touch panel
16 levels by software
Character font Chinese (simplified Chinese)
Japanese (ANK, Kanji)
Korean
ASCII
Taiwanese (traditional Chinese)
[Us] rated supply voltage 24 V DC
Supply voltage limits 19.2…28.8 V
Inrush current 30 A
Maximum power consumption in W 12 W when power is not supplied to external devices
7 W when backlight is OFF
8 W when backlight is dimmed
17 W
Local signalling Status LED green, steady offline
Status LED green, steady operating
Status LED orange, flashing software starting up
Status LED red, steady power supply (ON)
Status LED clear, faded power supply (OFF)
COM2 LED yellow, steady data is being transmitted
COM2 LED yellow, faded no data transmission
SD card LED green, steady card is inserted
SD card LED green, faded card is not inserted or is not being accessed
Software designation Vijeo Designer configuration software >= V6.1
Memory description Flash EPROM, 96 MB
Data backed up 512 kB internal RAM SRAM)
Data storage equipment SD card, <= 32 GB
SDHC card, <= 32 GB
Downloadable protocols Schneider Electric Modicon Modbus
Schneider Electric Modicon Uni-TE
Schneider Electric Modicon Modbus Plus
Schneider Electric Modicon FIPWAY
Mitsubishi Melsec third party protocols
Omron Sysmac third party protocols
Rockwell Automation Allen-Bradley third party protocols
Siemens Simatic third party protocols
Schneider Electric Modicon Modbus TCP
Integrated connection type COM1 serial link SUB-D 9 RS232C 2400…115200 bps
COM2 serial link RJ45 RS485 2400…115200 bps
COM2 serial link RJ45 RS485 187.5 kbps Siemens MPI
Ethernet RJ45 10BASE-T/100BASE-TX
Ethernet RJ45 IEEE 802.3
USB 2.0 type A
USB 2.0 type mini B
Product mounting Flush mounting
Fixing mode By 4 screw clamps
Front material PPT
Enclosure material PPT
Type of cooling Natural convection
Width 10.73 in (272.5 mm)
Height 8.44 in (214.5 mm)
Depth 2.24 in (57 mm)
Net weight 4.41 lb(US) (2 kg)

Environment

Standards UL 508
EN 61131-2
IEC 61000-6-2
Product certifications CULus
CE
C-Tick
KCC
UKCA
UKEX
Ambient air temperature for operation 32…131 °F (0…55 °C)
Ambient air temperature for storage -4…140 °F (-20…60 °C)
Relative humidity 10…90 % without condensation
Operating altitude < 2000 m
IP degree of protection IP20 IEC 60529 rear panel)
IP65 IEC 60529 front panel)
NEMA degree of protection NEMA 4X front panel (indoor use)
Shock resistance 147 m/s² 3 chocks in each direction X, Y and Z EN/IEC 61131-2
Vibration resistance 3.5 mm 5…9 Hz) – X, Y, Z directions for 10 cycles (approx. 100 min) – EN/IEC 61131-2
1 gn 9…150 Hz) – X, Y, Z directions for 10 cycles (approx. 100 min) – EN/IEC 61131-2
Resistance to electrostatic discharge 6 kV contact discharge IEC 61000-4-2 level 3

Packing Units

Unit Type of Package 1 PCE
Number of Units in Package 1 1
Package 1 Height 6.89 in (17.500 cm)
Package 1 Width 11.81 in (30.000 cm)
Package 1 Length 13.98 in (35.500 cm)
Package 1 Weight 5.79 lb(US) (2.625 kg)
Unit Type of Package 2 P12
Number of Units in Package 2 30
Package 2 Height 32.28 in (82.000 cm)
Package 2 Width 31.50 in (80.000 cm)
Package 2 Length 47.24 in (120.000 cm)
Package 2 Weight 220.46 lb(US) (100.000 kg)
