HMIDT651
- Unique HMI flexibility
- Intuitive and comfortable to operate
- High level of performance and openness
- Modular design allows easy installation and maintenance
- State-of-the-art wireless security protocols (WEB/WPA/WPA2)
-
Range of product Harmony GTU Product or component type Advanced touchscreen panel Terminal type Touchscreen display [Us] rated supply voltage 12…24 V DC power supply Supply voltage limits 10.8…28.8 V Power consumption in W 11.5 W Inrush current 30 A Touchscreen resolution 1024 x 1024 Pixel resolution 1280 x 800 Display size 12.1 inch Aspect ratio 4:3 Display type Colour TFT LCD Display resolution 1280 x 800 pixels WVGA Display colour 262144 colors Backlight lifespan 50000 hours Touch panel Single touch analogue resistive Type of cooling Natural convection Type of installation Indoor installation Cut-out dimensions 295 (+ 1/- 0) x 217 (+ 1/- 0) mm Width 308.5 mm Height 230.5 mm Depth 67 mm Net weight 3 kg IP degree of protection Front panel: IP66
Front panel: IP67NEMA degree of protection NEMA 4X front panel Standards UL 508
ANSI/ISA 12-12-01
Class I division 2 CSA C22.2 No 213
CSA C22.2 No 142
IEC 61132-2Product certifications CULus
KC
CE
RCM
UKCA
UKEXAmbient air temperature for operation 0…60 °C conforming to EN 61131-2 Ambient air temperature for storage -20…60 °C Relative humidity 10…90 % non-condensing Operating altitude 2000 m Vibration resistance 3.5 mm constant amplitude (f = 5…9 Hz) conforming to EN/IEC 61131-2
9.8 m/s² (f = 9…150 Hz) conforming to EN/IEC 61131-2Shock resistance 147 m/s² conforming to EN/IEC 61131-2 Electromagnetic compatibility Electrostatic discharge immunity test level 3 conforming to EN/IEC 61000-4-2 Unit Type of Package 1 PCE Number of Units in Package 1 1 Package 1 Height 18.6 cm Package 1 Width 33.0 cm Package 1 Length 43.0 cm Package 1 Weight 4.6 kg Unit Type of Package 2 CAR Number of Units in Package 2 2 Package 2 Height 42.0 cm Package 2 Width 34.5 cm Package 2 Length 46.0 cm Package 2 Weight 9.292 kg Unit Type of Package 3 P12 Number of Units in Package 3 20 Package 3 Height 110.0 cm Package 3 Width 80.0 cm Package 3 Length 120.0 cm Package 3 Weight 103.62 kg
